2021Maverick DS TURBO R
-
Performance
- 172 hp (128 kW)
- 64 in. width
- 20 in. (50.8 cm) of suspension travel
- 28 in. Maxxis† Bighorn 2.0 tires, 14 in. cast-aluminum wheels
![/content/dam/global/en/can-am-off-road/my21/photos/vehicle-line-up/ssv/maverick-x3/maverick-x3-ds-turbo-r/studio/MY21-Can-Am-Maverick-X3-DS-TurboR-CanAmRed-34Front-INTL.png]()
![can-am-red]()
RACE ONLY YOUR PULSE. New 64 in. DS Turbo R is your blend of more standard features & improved suspension across all terrains.
-
Differential
Selectable 2WD / 4WD with Visco-Lok† auto-locking front differential
-
Shocks
FOX† 2.5 PODIUM Piggyback with QS3†
-
Suspension
Front: Double A-arm with sway bar / Rear: 4-link TTX with sway bar
-
Protection
Integrated front bumper, Quarter-doors, HMWPE full skid plate
-
Features
Rear tow hook
Engine Engine - TURBO R
Engine displacement - 900
Type - 195 hp ( 145,4 kW ), Rotax ACE (Advanced Combustion Efficiency) 900 cc Turbocharged Triple-cylinder engine, liquid cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P
Drive Train - Selectable 2WD / 4WD with Visco-Lok+ auto-locking front differential
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tyres - Maxxis Bighorn 2.0† 28 x 9 x 14 in. (71.1 x 22.9 x 35.6 cm)
Rear Tyres - Maxxis Bighorn 2.0† 28 x 11 x 14 in. (71.1 x 27.9 x 35.6 cm)
Wheels - 14 in. (35.6 cm) cast-aluminum
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 132 x 64 x 65.4 in. (335.3 x 162.5 x 166.1 cm)
Wheel Base - 102 in. (259.1 cm)
Ground Clearance - 14 in. (35.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,481 lb (671.9 kg)
Rack Capacity - 200 lb (91 kg) with LinQ™ quick-attach
Storage Capacity - Total: 2.5 gal (9.4 L) Glove box: 1.6 gal (6.2 L) Central console: 0.8 gal (2.8 L) Cup holders: 0.1 gal (0.4 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Double A-arm with sway bar / 20 in. (50.8 cm) travel
Front Shocks - FOX† 2.5 PODIUM Piggyback with QS3† compression adjustment
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar / 20-in (50.8 cm) travel
Rear Shocks - FOX† 2.5 PODIUM Piggyback with QS3†compression adjustment and bottom-out control
Feature Gauge - 4.5 in. (11.4 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trips and hour meters, fuel, gear position, SPORT / ECO™ mode, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature, DPS mode
Instrumentation - Lighter type DC outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights
Winch - N/A
Protection - Integrated front bumper, Quarter-doors, HMWPE full skid plate, Rear tow hook
Warranty Factory - 2 years BRP limited warranty
-
-
-
Performance
- 195 hp (145 kW)
- 72 in. width
- Up to 24 in. (61 cm) of suspension travel
- Smart-Lok featuring 4WD TRAIL ACTIV mode
- 30 in. Maxxis† Bighorn 2.0 tires, 14 in. cast-aluminum beadlock wheels
![/content/dam/global/en/can-am-off-road/my21/photos/vehicle-line-up/ssv/maverick-x3/maverick-x3-x-rs-turbo-rr/studio/MY21-Can-Am-Maverick-X3-Xrs-TurboRR-TripleBlack-34Front-INTL.png]()
![triple-black]()
MAKE THE WORLD YOUR STAGE. Front and rear FOX shocks are serious hardware to help you harness all 195 horses on any terrain, anywhere—and do it all again tomorrow.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD
-
Shocks
Front: FOX† 2.5 PODIUM RC2† Piggyback / Rear: FOX† 3.0 PODIUM RC2† Piggyback
-
Suspension
Front: Double A-arm with sway bar and trophy truck inspired arms / Rear: 4-link TTX with sway bar
-
Protection
Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate
-
Features
7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook
Engine Engine - TURBO RR
Engine displacement - 900
Type - 195 hp ( 145,4 kW ), Rotax ACE (Advanced Combustion Efficiency) 900 cc Turbocharged Triple-cylinder engine, liquid cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P
Drive Train - Lockable front differential with exclusive Smart-Lok * technology. True 4 modes traction system: 2WD / 4WD with front diff. lock / 4WD TRAIL ACTIV / 4WD TRAIL *Smart-Lok was developed in conjunction with TEAM Industries, a market leader in the drive train industry
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tyres - Maxxis Bighorn 2.0† 30 x 9 x 14 in. (76.2 x 22.9 x 35.6 cm)
Rear Tyres - Maxxis Bighorn 2.0† 30 x 11 x 14 in. (76.2 x 27.9 x 35.6 cm)
Wheels - 14 in. (35.6 cm) cast-aluminum beadlock
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 132 x 72.7 x 68.5 in. (335.3 x 184.7 x 174 cm)
Wheel Base - 102 in. (259.1 cm)
Ground Clearance - 16 in. (40.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,627 lb (738 kg)
Rack Capacity - 200 lb (91 kg) with LinQ™ quick-attach
Storage Capacity - Total: 2.5 gal (9.4 L) Glove box: 1.6 gal (6.2 L) Central console: 0.8 gal (2.8 L) Cup holders: 0.1 gal (0.4 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Double A-arm with sway bar / 22 in. (55.9 cm) travel / Trophy truck inspired arms
Front Shocks - FOX† 2.5 PODIUM RC2† Piggyback with bypass, dual speed compression and rebound adjustments
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar / 24-in (61 cm) travel
Rear Shocks - FOX† 3.0 PODIUM RC2† remote reservoir with bypass, dual speed compression and rebound adjustments
Feature Gauge - 7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trips and hour meters, fuel, gear position, SPORT / ECO modes, seat belt and 4 x4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature, DPS mode
Instrumentation - Lighter type DC outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights with unique Can-Am LED signature
Winch - N/A
Protection - Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate, Rear tow hook
Warranty Factory - 2 years BRP limited warranty
-
-
-
Performance
- 195 hp (145 kW)
- 72 in. width
- 22 in. (55.9 cm) of suspension travel
- Smart-Shox Technology, Smart-Lok featuring 4WD TRAIL ACTIV mode
- 30 in. Maxxis† Bighorn 2.0 tires, 14 in. cast-aluminum beadlock wheels
![/content/dam/global/en/can-am-off-road/my21/photos/vehicle-line-up/ssv/maverick-x3/maverick-x3-x-rs-turbo-rr/studio/MY21-Can-Am-Maverick-X3-XrsSAS-TurboRR-MacchiatoSatin-Black-CanAmRed-34Front-NA.png]()
![desert-tan--carbon-black---can-am-red]()
BUILT FOR THE VICTORY LAP. Run at the front of any pack with 195 horsepower, FOX 3.0 PODIUM suspension, Smart-Lok™ differential featuring Trail Activ mode—and up to 4 seats.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD
-
Shocks
Front: FOX† 2.5 PODIUM Piggyback with bypass and Smart-Shox Technology / Rear: FOX† 3.0 PODIUM Remote reservoir with bypass and Smart-Shox Technology
-
Suspension
Front: Trophy truck inspired double A-arm with sway bar / Rear: 4-link TTX with sway bar
-
Protection
Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate
-
Features
7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook
Engine Engine - TURBO RR
Engine displacement - 900
Type - 195 hp ( 145,4 kW ), Rotax ACE (Advanced Combustion Efficiency) 900 cc Turbocharged Triple-cylinder engine, liquid cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P
Drive Train - Lockable front differential with exclusive Smart-Lok * technology. True 4 modes traction system: 2WD / 4WD with front diff. lock / 4WD TRAIL ACTIV / 4WD TRAIL *Smart-Lok was developed in conjunction with TEAM Industries, a market leader in the drive train industry
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tyres - Maxxis Bighorn 2.0† 30 x 9 x 14 in. (76.2 x 22.9 x 35.6 cm)
Rear Tyres - Maxxis Bighorn 2.0† 30 x 11 x 14 in. (76.2 x 27.9 x 35.6 cm)
Wheels - 14 in. (35.6 cm) cast-aluminum beadlock
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 132 x 72.7 x 68.5 in. (335.3 x 184.7 x 174 cm)
Wheel Base - 102 in. (259.1 cm)
Ground Clearance - 16 in. (40.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,646 lb (747 kg)
Rack Capacity - 200 lb (91 kg) with LinQ™ quick-attach
Storage Capacity - Total: 2.5 gal (9.4 L) Glove box: 1.6 gal (6.2 L) Central console: 0.8 gal (2.8 L) Cup holders: 0.1 gal (0.4 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Double A-arm with sway bar / 22 in. (55.9 cm) travel / Trophy truck inspired arms
Front Shocks - FOX† 2.5 PODIUM† Piggyback with bypass and Smart-Shox** Technology featuring DDA Valve (Dynamic Damping Adjustment)
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar / 24-in (61 cm) travel
Rear Shocks - FOX† 3.0 PODIUM† remote reservoir with bypass and Smart-Shox** Technology featuring DDA Valve (Dynamic Damping Adjustment) **Smart-Shox was developed in conjunction with Tractive Industries, a market leader in the suspension industry
Feature Gauge - 7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trips and hour meters, fuel, gear position, SPORT / ECO modes, seat belt and 4 x4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature, DPS mode
Instrumentation - Lighter type DC outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights with unique Can-Am LED signature
Winch - N/A
Protection - Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate, Rear tow hook
Warranty Factory - 2 years BRP limited warranty
-
-
-
Rock Crawling
- Performance
- 195 hp (145 kW)
- 72 in. width
- Up to 24 in. (61 cm) suspension travel
- Smart-Lok featuring 4WD ROCK mode
- 32 in. Maxxis† Liberty 2.0 tires, 15 in. cast-aluminum beadlock wheels
![/content/dam/global/en/can-am-off-road/my21/photos/vehicle-line-up/ssv/maverick-x3/maverick-x3-x-rc-turbo-rr/studio/MY21-Can-Am-Maverick-X3-Xrc-TurboRR-ChalkGrey-MagmaRed-34Front-INTL.png]()
![chalk-grey---magma-red]()
ROCK ON ROCKS. Test your mettle and finally conquer the last mile: The Maverick X3 X rc Turbo RR is the ultimate factory rock-crawling side-by-side vehicle for leaving rivals at the bottom of the heap. Four-link TTX suspension with 24-in. of travel features a trophy truck-like trailing arm and front double arched A-arm with sway bar.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD ROCK / 4WD TRAIL / 2WD / 4WD
-
Shocks
Front: FOX† 2.5 PODIUM RC2† Piggyback / Rear: FOX† 3.0 PODIUM RC2† Piggyback
-
Suspension
Front: Trophy truck inspired arched double A-arm with sway bar / Rear: 4-link TTX with sway bar and arched lower links
-
Protection
Front bumper, Half-doors, Aluminum roof, Intrusion bar, 4-point harness with shoulder pads, UHMWPE rock sliders, HMWPE skidplates, Full heavy duty with differential / Under bumper / Front and rear suspension arm
-
Features
4,500-lb winch with synthetic rope, 7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook
Engine Engine - TURBO RR
Engine displacement - 900
Type - 195 hp( 145,4 kW ), Rotax ACE (Advanced Combustion Efficiency) 900 cc Turbocharged Triple-cylinder engine, liquid cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P
Drive Train - Lockable front differential with exclusive Smart-Lok* technology. True 4 modes traction system: 2WD / 4WD with front diff. lock / 4WD ROCK / 4WD TRAIL *Smart-Lok was developed in conjunction with TEAM Industries, a market leader in the drive train industry
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tyres - Maxxis Liberty† 32 x 10 x 15 in. (81.3 x 25.4 x 38.1 cm)
Rear Tyres - Maxxis Liberty† 32 x 10 x 15 in. (81.3 x 25.4 x 38.1 cm)
Wheels - 15 in. (38.1 cm) cast-aluminum beadlock
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 134.5 x 72.8 x 68.5 in. (341.6 x 184.9 x 174 cm)
Wheel Base - 102 in. (259.1 cm)
Ground Clearance - 16 in. (40.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,811 lb (821.5 kg)
Rack Capacity - 200 lb (91 kg) with LinQ™ quick-attach
Storage Capacity - Total: 2.5 gal (9.4 L) Glove box: 1.6 gal (6.2 L) Central console: 0.8 gal (2.8 L) Cup holders: 0.1 gal (0.4 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Trophy truck inspired double arched A-arm with sway bar / 22 in. (55.9 cm) travel
Front Shocks - FOX† 2.5 PODIUM RC2† Piggyback with bypass, dual speed compression and rebound adjustments
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar and arched lower links / 24 in. (61 cm) travel
Rear Shocks - FOX† 3.0 PODIUM RC2† remote reservoir with bypass, dual speed compression and rebound adjustments
Feature Gauge - 7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trips and hour meters, fuel, gear position, SPORT / ECO modes, seat belt and 4 x4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature, DPS mode
Instrumentation - Lighter type DC outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights with unique Can-Am LED signature
Winch - 4,500-lb (2,041 kg) winch with synthetic rope
Protection - Front bumper, Half-doors, Aluminum roof, Intrusion bar, 4-point harness with shoulder pads, UHMWPE rock sliders, HMWPE skidplates: Full heavy duty with differential, Under bumper, Front and rear suspension arm, Rear tow hook
Warranty Factory - 2 years BRP limited warranty
-
-
-
Performance
- 195 hp (145 kW)
- 72 in. width
- 22 in. (55.9 cm) of suspension travel
- Smart-Shox Technology, Smart-Lok featuring 4WD TRAIL ACTIV mode
- 30 in. Maxxis† Bighorn 2.0 tires, 14 in. cast-aluminum beadlock wheels
![/content/dam/global/en/can-am-off-road/my21/photos/vehicle-line-up/ssv/maverick-x3-max/maverick-x3-max-x-rs-turbo-rr/studio/MY21-Can-Am-Maverick-Max-X3-XrsSAS-TurboRR-MacchiatoSatin-Black-CanAmRed-34Front-NA.png]()
![desert-tan--carbon-black---can-am-red]()
BUILT FOR THE VICTORY LAP. Run at the front of any pack with 3 of your friends, 195 horsepower, Smart-Lok™ differential featuring Trail Activ mode and Smart-Shox semi-active suspension.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD
-
Shocks
Front: FOX† 2.5 PODIUM Piggyback with bypass and Smart-Shox Technology / Rear: FOX† 3.0 PODIUM Remote reservoir with bypass and Smart-Shox Technology
-
Suspension
Front: Trophy truck inspired double A-arm with sway bar / Rear: 4-link TTX with sway bar
-
Protection
Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate
-
Features
7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook
Engine Engine - TURBO RR
Engine displacement - 900
Type - 195 hp, Rotax ACE (Advanced Combustion Efficiency) 900 cc Turbocharged Triple-cylinder engine, liquid cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P
Drive Train - Lockable front differential with exclusive Smart-Lok * technology. True 4 modes traction system: 2WD / 4WD with front diff. lock / 4WD TRAIL ACTIV / 4WD TRAIL *Smart-Lok was developed in conjunction with TEAM Industries, a market leader in the drive train industry
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tyres - Maxxis Bighorn 2.0† 30 x 9 x 14 in. (76.2 x 22.9 x 35.6 cm)
Rear Tyres - Maxxis Bighorn 2.0† 30 x 11 x 14 in. (76.2 x 27.9 x 35.6 cm)
Wheels - 14 in. (35.6 cm) cast-aluminum beadlock
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 165 x 72.7 x 68.5 in. (419.1 x 184.7 x 174 cm)
Wheel Base - 135 in. (342.9 cm)
Ground Clearance - 16 in. (40.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,877 lb (851 kg)
Rack Capacity - 150 lb (68 kg) with LinQ™ quick-attach
Storage Capacity - Total: 3 gal (11.4 L) Glove box: 1.6 gal (6.2 L) Central console: 1.1 gal (4.1 L) Cup holders: 0.3 gal (1.1 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Double A-arm with sway bar / 22 in. (55.9 cm) travel / Trophy truck inspired arms
Front Shocks - FOX† 2.5 PODIUM† Piggyback with bypass and Smart-Shox** Technology featuring DDA Valve (Dynamic Damping Adjustment)
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar / 22 in. (55.9 cm) travel
Rear Shocks - FOX† 3.0 PODIUM† remote reservoir with bypass and Smart-Shox** Technology featuring DDA Valve (Dynamic Damping Adjustment) **Smart-Shox was developed in conjunction with Tractive Industries, a market leader in the suspension industry
Feature Gauge - 7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trips and hour meters, fuel, gear position, SPORT / ECO modes, seat belt and 4 x4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature, DPS mode
Instrumentation - Lighter type DC outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights with unique Can-Am LED signature
Winch - N/A
Protection - Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate, Rear tow hook
Warranty Factory - 2 years BRP limited warranty
-
Download spec sheet
