2022

Traxter DPS HD9

Work

65 hp ( 48 kW )
Up to 11 in. (28 cm) ground clearance
27-in. XPS Trail Force tires
VERSA-PRO bench seat
Dynamic Power Steering (DPS)

Compare

Traxter DPS HD9

TAKE THE REIGNS. Dynamic Power Steering (DPS) makes for a workhorse that drives well at every turn. Fill the adaptable storage, engage 4WD, and drive the best without stretching your wallet.

Engine

HD9: Rotax® 976 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Double A-arm / Rear: TTA with external sway bar
Protection

Integrated front steel bumper, HMWPE central skid plate

Download spec sheet

Engine
Engine	HD9
Engine displacement	799
Type	HD9: 65 hp ( 37 kW ), Rotax 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	XPS Trail Force 27 x 9 x 14 in.
Rear Tyres	XPS Trail Force 27 x 11 x 14 in.
Wheels	14-in. (35.6 cm) cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers

Dimensions
L x W x H	121 x 62 x 76 in. (307.1 x 157.5 x 193 cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	11 in. (28 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1541 lb (698.8 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 10.4 gal (39.5 L) Under dash: 6 gal (22.8 L) Dash: 1.8 gal (6.9 L) Water-resistant and removable toolbox: 1.7 gal (6.3 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Double A-arm / 10 in. (25.4 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	TTA with external sway bar / 10 in. (25.4 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. (11.4 cm) wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (18 amp/h)
Magneto	650 W
Instrumentation	Lighter type DC outlet in console (20-A)
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	N/A
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE central skid plate
Hitch Type	2-in. hitch receiver

Warranty
Factory	2 years BRP limited warranty

2022

Traxter BASE HD9 T

Work
EC homologated T category
Up to 60 km/h

65 hp ( 48 kW )
11 in. (28 cm) ground clearance
27-in. Maxxis† Coronado tires
VERSA-PRO bench seat
7.6” digital display

Compare

Traxter BASE HD9 T

DO IT ALL. The toughest, most capable Can-Am ever—exceptional work abilities & adaptible to any use at a price too good to pass up.

Up to 60 km/h

Engine

HD9: Rotax® 976 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14-in. (35.6 cm) steel wheels
Suspension

Front: Double A-arm / Rear: TTA with external sway bar
Protection

Integrated front steel bumper HMWPE central skid plate

Download spec sheet

Engine
Engine	HD9
Engine displacement	799
Type	HD9: 65 hp ( 37 kW ), Rotax 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok† auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	N/A

Tires/Wheels
Front Tyres	XPS Trail Force 27 x 9 x 14 in.
Rear Tyres	XPS Trail Force 27 x 11 x 14 in.
Wheels	14 in. steel

Breaks
Front	Dual 220 mm disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm disc brakes with hydraulic single-piston calipers

Dimensions
L x W x H	121 x 62 x 76 in. (307.1 x 157.5 x 193 cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	11 in. (28 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1,479 lb (671 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg) / California only: 600 lb (272.2 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 3.1 gal (11.7 L) Under dash (enclosed pocket) : 0.4 gal (1.3 L) Dash: 1.8 gal (6.9 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Double A-arm / 10 in. (25.4 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	TTA with external sway bar / 10 in. (25.4 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. (11.4 cm) wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (18 amp/h)
Magneto	650W
Instrumentation	Lighter type DC outlet in console (20-A)
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	N/A
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE central skid plate
Hitch Type	2-in. hitch receiver, 7-pin trailer connection (12V)

Warranty
Factory	2 years BRP limited warranty

2022

Traxter XT HD10

Work

82 hp ( 61 kW)
Up to 13 in. (33 cm) ground clearance
27-in. Maxxis† Bighorn 2.0 tires
VERSA-PRO bench seat with bolster seats, reinforced XT seat skin and adjustable driver seat
Dynamic Power Steering (DPS)

Compare

Traxter XT HD10

EQUIPPED TO GET IT DONE. Full exterior protection and factory installed winch plus choice accessories from bumper to bumper— the Traxter XT is ready when you are.

Engine

HD10: Rotax® 976 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Arched double A-arm / Rear: Arched TTA with external sway bar
Protection

XT front bumper, HMWPE full skid plate, Full hard roof

Download spec sheet

Engine
Engine	HD10
Engine displacement	976
Type	HD10: 82 hp ( 61 kW), Rotax® 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok QE auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	Maxxis Bighorn 2.0† 27 x 9 x 14 in
Rear Tyres	Maxxis Bighorn 2.0† 27 x 11 x 14 in.
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers

Dimensions
L x W x H	125.7 x 64 x 80 in. (319,4 x 162.5 x 203.2cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	13 in. (33 cm)
Chassis Cage	Profiled cage ROPS approved
Dry Weight	1,600.6 lb (726 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 16.2 gal (61.3 L) Under dash: 6 gal (22.8 L) Waterproof and removable box under passenger seat: 5.6 gal (21 L) Dash: 2 gal (7.7 L) Water-resistant and removable toolbox: 1.7 gal (6.3 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Arched double A-arm / 11 in. (27.9 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	Arched TTA with external sway bar / 11 in. (27.9 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. (11.4 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (30 amp/h)
Magneto	650 W
Instrumentation	Lighter type DC outlets in the console (20-A) and two USB port in the dash storage
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	4,500-lb (2,041 kg) winch with roller fairlead
Seat	VERSA-PRO bench seat with passenger seats flipping up, adjustable driver seat, underside hooks, reinforced XT seat skin and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	XT front bumper , HMWPE full skid plate, full hard roof
Hitch Type	2-in. hitch receiver

Warranty
Factory	2 years BRP limited warranty

2022

Traxter PRO DPS HD10

Work

82 hp (61 kW)
13 in. (33 cm) ground clearance
28 in. Maxxis† Bighorn 2.0 tires
VERSA-PRO bench seat
Lower Storage 316.5 L, Integrated front steel bumper

Compare

Traxter PRO DPS HD10

PERFECT PLATFORM. The world’s best Can-Am with a 1.37 x 1.82 m bed and the torque to haul like nothing else off-road. On the job, farm, ranch, hunting trip and leisure rides, Traxter PRO was built to stretch what a side-by-side vehicle can do. More than 60 km/h

Engine

HD10: Rotax® 976 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14 in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Arched double A-arm / Rear: Arched TTA with external sway bar
Protection

Integrated front steel bumper, HMWPE central skid plate

Download spec sheet

Engine
Engine	HD10
Engine displacement	976
Type	HD10: 82 hp ( 61 kW), Rotax 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	Maxxis Bighorn 2.0† 28 x 9 x 14 in. (71.1 x 22.9 x 35.6 cm)
Rear Tyres	Maxxis Bighorn 2.0† 28 x 11 x 14 in. (71.1 x 27.9 x 35.6 cm)
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers

Dimensions
L x W x H	154.1 x 64 x 78 (391.5 x 162.5 x 198.1 cm)
Wheel Base	115.5 in. (294 cm)
Ground Clearance	13 in. (33 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1833 lb (831.5 kg)
Cargo Box Dimensions	72 x 54.5 x 10 in. (180,3 x 138.4 x 25.4 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 94 gal (356 L) Under dash: 6 gal (22.8 L) Dash: 1.8 gal (6.9 L) Water-resistant and removable toolbox: 1.7 gal (6.3 L) Armrests and cup holders: 0.9 gal (3.5 L) 83.6 gal (316.5 L) Lower box storage 83.6 gal (316.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1700 lb (771 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Arched double A-arm / 11 in. (27.9 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	Arched TTA with external sway bar / 11 in. (27.9 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (30 amp/h)
Magneto	650 W
Instrumentation	Two lighter type DC outlets, one in the console (20-A) and one in the under dash storage (20-A)
Lighting	140-W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	N/A
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE central skid plate
Hitch Type	2-in. hitch receiver, 7-pin trailer connection (12V)

Warranty
Factory	2 years BRP limited warranty

2022

Traxter MAX DPS HD9

Work

65 hp ( 48 kW )
Up to 11 in. (28 cm) ground clearance
27-in. XPS Trail Force tires
VERSA-PRO bench seat
Dynamic Power Steering (DPS)

Compare

Traxter MAX DPS HD9

TAKE THE REIGNS. Dynamic Power Steering (DPS) makes for a workhorse that drives well at every turn. Fill the adaptable storage, engage 4WD, and drive the best without stretching your wallet.

Engine

HD9: Rotax® 976 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Double A-arm / Rear: TTA with external sway bar
Protection

Integrated front steel bumper, HMWPE central skid plate

Download spec sheet

Engine
Engine	HD9
Engine displacement	799
Type	HD9: 65 hp ( 37 kW ), Rotax 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok QE auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	XPS Trail Force 27 x 9 x 14 in.
Rear Tyres	XPS Trail Force 27 x 11 x 14 in.
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers

Dimensions
L x W x H	153.4 x 63.5 x 76 in. (389.6 x 161.2 x x 193 cm)
Wheel Base	115.5 in. (294 cm)
Ground Clearance	11 in. (28 cm)
Chassis Cage	Profiled cage ROPS approved
Dry Weight	1,771 lb (803.2 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 11.1 gal (42.1 L) Under dash: 6 gal (22.8 L) Dash: 1.8 gal (6.9 L) Water-resistant and removable toolbox: 1.7 gal (6.3 L) Armrests and cup holders: 1.6 gal (6.1 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,750 lb (793,8 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	6

Suspensions
Front Suspension	Double A-arm / 10 in. (25.4 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	TTA with external sway bar / 10 in. (25.4 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. (11.4 cm) wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (18 amp/h)
Magneto	650 W
Instrumentation	Lighter type DC outlet in console (20-A)
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	N/A
Seat	Dual VERSA-PRO bench seats with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper, HMWPE central skid plate
Hitch Type	2-in. hitch receiver

Warranty
Factory	2 years BRP limited warranty

2022

Traxter XU HD9 T

Work
EC homologated T category
More than 60 km/h

65 hp ( 48 kW )
11 in. (28 cm) ground clearance
27-in. Maxxis† Coronado tires
2,041 kg winch
Dynamic Power Steering (DPS)

Compare

Traxter XU HD9 T

READY TO TAKE THE JOB. The new Traxter XU comes equipped with many factory-installed accessories including 27” Maxxis Coronado tires mounted on 14” wheels, winch, Anti-locking Braking System (ABS) and Tri-Mode Dynamic Power Steering for better handling and steering. More than 60 km/h

/content/dam/global/en/can-am-off-road/my22/photos/vehicle-lineup/ssv/traxter/traxter-xu/ORV-SSV-MY22-Can-Am-Traxter-XU-HD9TR-Stone-Gray-SKU0006NNB00-34FR-CE.png

READY TO TAKE THE JOB. The new Traxter XU comes equipped with many factory-installed accessories including 27” Maxxis Coronado tires mounted on 14” wheels, winch, Anti-locking Braking System (ABS) and Tri-Mode Dynamic Power Steering for better handling and steering. More than 60 km/h

Engine

Rotax® 799.9 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Arched Double A-arm / Rear: Arched TTA with external sway bar
Protection

Integrated front steel bumper, Full skid plate

Download spec sheet

Engine
Engine	HD9
Engine displacement	799
Type	HD9: 65 hp ( 37 kW ), Rotax 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential Open front Differential with ABS system Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential Open front Differential with ABS system
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	Maxxis Coronado 2.0† 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm)
Rear Tyres	Maxxis Coronado 2.0† 27 x 11 x 14 in. (68.6 x 27.9 x 35.6 cm)
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers
Technology	Brake holding mechanism

Dimensions
L x W x H	121 x 62 x 76 in. (307.1 x 157.5 x 193 cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	11 in. (28 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1,572 lb (713 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 6.5 gal (24.5 L) Waterproof and removable box under passenger seat: 5.6 gal (21 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Arched double A-arm / 11 in. (27.9 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	Arched TTA with external sway bar / 11 in. (27.9 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (30 amp/h)
Magneto	650W
Instrumentation	Two lighter type DC outlets, one in the console (20-A) and one in the under dash storage (20-A)
Lighting	140-W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	4,500-lb (2,041 kg) winch with roller fairlead
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE full skid plate
Hitch Type	2-in. hitch receiver, 7-pin trailer connection (12V)

Warranty
Factory	2 years BRP limited warranty

2022

Traxter PRO DPS HD10 T

Work
EC homologated T category
More than 60 km/h

82 hp (61 kW)
13 in. (33 cm) ground clearance
27 in. Maxxis† Coronado tires
1,136 kg towing capacity
Dynamic Power Steering (DPS)

Compare

Traxter PRO DPS HD10 T

PERFECT PLATFORM. The world’s best Can-Am with a 1.37 x 1.82 m bed and the torque to haul like nothing else off-road. On the job, farm, ranch, hunting trip and leisure rides, Traxter PRO was built to stretch what a side-by-side vehicle can do. More than 60 km/h

/content/dam/global/en/can-am-off-road/my22/photos/vehicle-lineup/ssv/traxter/traxter-pro-dps/ORV-SSV-MY22-Can-Am-Traxter-PRO-DPS-HD10TR-Timeless-Black-SKU0006ANF00-34FR-CE.png

PERFECT PLATFORM. The world’s best Can-Am with a 1.37 x 1.82 m bed and the torque to haul like nothing else off-road. On the job, farm, ranch, hunting trip and leisure rides, Traxter PRO was built to stretch what a side-by-side vehicle can do. More than 60 km/h

Engine

Rotax® 976 cc V-twin
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14 in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Arched double A-arm with sway bar / Rear: Arched TTA with external sway bar
Protection

Integrated front steel bumper, HMWPE central skid plate

Download spec sheet

Engine
Engine	HD10
Engine displacement	976
Type	82 hp / 69 lb-ft, Rotax® 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD
Driving Assistance	Brake holding mechanism, Electronic Hill Descent Control, ECO™ / ECO™ Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	Maxxis Bighorn 2.0† 28 x 11 x 14 in.
Rear Tyres	Maxxis Bighorn 2.0† 28 x 11 x 14 in.
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm disc brakes with hydraulic twin-piston calipers

Dimensions
L x W x H	154.1 x 64 x 78 (391.5 x 162.5 x 198.1 cm)
Wheel Base	115.5 in. (294 cm)
Ground Clearance	13 in. (33 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1833 lb (831.5 kg)
Cargo Box Dimensions	72 x 54.5 x 10 in. (180,3 x 138.4 x 25.4 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 92.3 gal (350 L) Under dash: 6 gal (22.8 L) Dash: 1.8 gal (6.9 L) Armrests and cup holders: 0.9 gal (3.5 L) Lower box storage 83.6 gal (316.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1700 lb (771 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Arched double A-arm / 11 in. (27.9 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	Arched TTA with external sway bar / 11 in. (27.9 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (18 amp/h)
Magneto	650 W
Instrumentation	Lighter type DC outlet in console (20-A)
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and Premium LED tail lights
Winch	N/A
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE central skid plate Front fender extension
Hitch Type	2-in hitch receiver with rear hitch and tow ball

Warranty
Factory	2 years BRP limited warranty

2022

Traxter XU HD7 T

Work
EC homologated T category
Up to 60 km/h

52 hp ( 38 kW )
Up to 11 in. (28 cm) ground clearance
27-in. Maxxis† Coronado tires
2,041 kg winch
Dynamic Power Steering (DPS)

Compare

Traxter XU HD7 T

READY TO TAKE THE JOB. The Traxter XU comes equipped with many factory-installed accessories including 27” Maxxis Coronado tires mounted on 14” wheels, winch and Tri-Mode Dynamic Power Steering for better handling and steering.

Up to 60 km/h

Engine

HD7: Rotax 650 cc single cylinder, liquid cooled
Transmission

CVT
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Double A-arm / Rear: TTA with external sway bar
Protection

Integrated front steel bumper, Full skid plate

Download spec sheet

Engine
Engine	HD7
Engine displacement	650
Type	HD7: 52 hp ( 28 kW ), Rotax 650 cc single cylinder, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PDrive primary CVT with engine braking and Electronic Drive Belt Protection L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	Maxxis Coronado 2.0† 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm)
Rear Tyres	Maxxis Coronado 2.0† 27 x 11 x 14 in. (68.6 x 27.9 x 35.6 cm)
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers
Technology	Brake holding mechanism

Dimensions
L x W x H	121 x 62 x 76 in. (307.1 x 157.5 x 193 cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	11 in. (28 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1,516 lb (687.8 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 6.5 gal (24.5 L) Waterproof and removable box under passenger seat: 5.6 gal (21 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Double A-arm / 10 in. (25.4 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	TTA with external sway bar / 10 in. (25.4 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (30 amp/h)
Magneto	650W
Instrumentation	Two lighter type DC outlets, one in the console (20-A) and one in the under dash storage (20-A)
Lighting	140-W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	4,500-lb (2,041 kg) winch with roller fairlead
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE full skid plate
Hitch Type	2-in. hitch receiver, 7-pin trailer connection (12V)

Warranty
Factory	2 years BRP limited warranty

2022

Traxter BASE HD7 T

Work
EC homologated T category
Up to 60 km/h

52 hp ( 38 kW )
11 in. (28 cm) ground clearance
27-in. Maxxis† Coronado tires
VERSA-PRO bench seat
7.6” digital display

Compare

Traxter BASE HD7 T

When we engineered the Can-Am Traxter, we pulled out all the stops. We made it tough, capable and clever to excel at everything you demand of it. You'll feel the difference as soon as you sit in and pull away.

Up to 60 km/h

Engine

HD7: Rotax 650 cc single cylinder, liquid cooled
Transmission

CVT
Wheels

14-in. (35.6 cm) steel wheels
Suspension

Front: Double A-arm / Rear: TTA with external sway bar
Protection

Integrated front steel bumper HMWPE central skid plate

Download spec sheet

Engine
Engine	HD7
Engine displacement	650
Type	HD7: 52 hp ( 28 kW ), Rotax 650 cc single cylinder, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PDrive primary CVT with engine braking and Electronic Drive Belt Protection L / H / N / R / P
Drive Train	Selectable 2WD / 4WD with Visco-Lok† auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	N/A

Tires/Wheels
Front Tyres	XPS Trail Force 27 x 9 x 14 in.
Rear Tyres	XPS Trail Force 27 x 11 x 14 in.
Wheels	14 in. steel

Breaks
Front	Dual 220 mm disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm disc brakes with hydraulic single-piston calipers

Dimensions
L x W x H	121 x 62 x 76 in. (307.1 x 157.5 x 193 cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	11 in. (28 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1,475 lb (669.2 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg) / California only: 600 lb (272.2 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 3.1 gal (11.7 L) Under dash (enclosed pocket) : 0.4 gal (1.3 L) Dash: 1.8 gal (6.9 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Double A-arm / 10 in. (25.4 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	TTA with external sway bar / 10 in. (25.4 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. (11.4 cm) wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (18 amp/h)
Magneto	650W
Instrumentation	Lighter type DC outlet in console (20-A)
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	N/A
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE central skid plate
Hitch Type	2-in. hitch receiver with tow ball, 7-pin trailer connection (12V)

Warranty
Factory	2 years BRP limited warranty

2022

Traxter MAX DPS HD10 T

Work
EC homologated T category
More than 60 km/h

82 hp ( 61 kW)
12.5 in. (31.8 cm) ground clearance
27-in. Maxxis† Coronado tires
VERSA-PRO bench seat
Dynamic Power Steering (DPS)

Compare

Traxter MAX DPS HD10 T

TAKE IT ON, BRING IT ALONG. Comfortable Power Steering turns the Traxter MAX into a workhorse that makes your job even easier. With the heavy-duty Rotax engine, capasity of 6 persons and adaptable storage you get it done. More than 60 km/h

Engine

HD10: Rotax® 976 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Arched Double A-arm / Rear: Arched TTA with external sway bar
Protection

Integrated front steel bumper, HMWPE central skid plate

Download spec sheet

Engine
Engine	HD10
Engine displacement	976
Type	HD10: 82 hp ( 61 kW), Rotax® 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok QE auto-locking front Differential
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	Maxxis Bighorn 2.0† 27 x 9 x 14 in.
Rear Tyres	Maxxis Bighorn 2.0† 27 x 11 x 14 in.
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers

Dimensions
L x W x H	153.4 x 63.5 x 76 in. (389.6 x 161.2 x x 193 cm)
Wheel Base	115.5 in. (294 cm)
Ground Clearance	12.5 in. (31.8 cm)
Chassis Cage	Profiled cage ROPS approved
Dry Weight	1,771 lb (803.2 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 11.1 gal (42.1 L) Under dash: 6 gal (22.8 L) Dash: 1.8 gal (6.9 L) Water-resistant and removable toolbox: 1.7 gal (6.3 L) Armrests and cup holders: 1.6 gal (6.1 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,750 lb (793,8 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	6

Suspensions
Front Suspension	Arched double A-arm / 11 in. (27.9 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	Arched TTA with external sway bar / 11 in. (27.9 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	4.5 in. wide digital display: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (18 amp/h)
Magneto	650 W
Instrumentation	Lighter type DC outlet in console (20-A)
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	N/A
Seat	Dual VERSA-PRO bench seats with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper, HMWPE central skid plate
Hitch Type	2-in. hitch receiver with tow ball, 7-pin trailer connection (12V)

Warranty
Factory	2 years BRP limited warranty

2022

Traxter XU HD10 T

Work
EC homologated T category
More than 60 km/h

82 hp ( 61 kW )
13 in. (33 cm) ground clearance
27-in. Maxxis† Coronado tires
2,041 kg winch
Dynamic Power Steering (DPS)

Compare

Traxter XU HD10 T

READY TO TAKE THE JOB. The new Traxter XU comes equipped with many factory-installed accessories including 27” Maxxis Coronado tires mounted on 14” wheels, winch, Anti-locking Braking System (ABS) and Tri-Mode Dynamic Power Steering for better handling and steering.

More than 60 km/h

Engine

HD10: Rotax® 976 cc V-twin, liquid cooled
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Arched Double A-arm / Rear: Arched TTA with external sway bar
Protection

Integrated front steel bumper, Full skid plate

Download spec sheet

Engine
Engine	HD10
Engine displacement	976
Type	HD10: 82 hp ( 61 kW), Rotax 976 cc, V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), high airflow ventilation and Electronic Drive Belt Protection Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD with Visco-Lok† QE auto-locking front Differential Open front Differential with ABS system
Driving Assistance	Electronic Hill Descent Control ECO™ / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	Maxxis Coronado 2.0† 27 x 9 x 14 in. (68.6 x 22.9 x 35.6 cm)
Rear Tyres	Maxxis Coronado 2.0† 27 x 11 x 14 in. (68.6 x 27.9 x 35.6 cm)
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers
Technology	Brake holding mechanism

Dimensions
L x W x H	125.7 x 64 x 80 in. (319,4 x 162.5 x 203.2cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	13 in. (33 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1,594 lb (723 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 6.5 gal (24.5 L) Waterproof and removable box under passenger seat: 5.6 gal (21 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Arched double A-arm / 11 in. (27.9 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	Arched TTA with external sway bar / 11 in. (27.9 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (30 amp/h)
Magneto	650 W
Instrumentation	Two lighter type DC outlets, one in the console (20-A) and one in the under dash storage (20-A)
Lighting	140-W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	4,500-lb (2,041 kg) winch with roller fairlead
Seat	VERSA-PRO bench seat with passenger seats flipping up, underside hooks and contoured bench to improve entrance/exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Integrated front steel bumper HMWPE full skid plate
Hitch Type	2-in. hitch receiver, 7-pin trailer connection (12V)

Warranty
Factory	2 years BRP limited warranty

2022

Traxter X mr HD10

Performance
Hunting
Trail

82 hp ( 61 kW)
15 in. (38.1 cm) ground clearance
30-in. ITP Cryptid† tires
VERSA-PRO bench seat with bolster seats, reinforced seat skin featuring X package trims and adjustable driver seat
Exclusive Smart-Lok™ technology

Compare

Traxter X mr HD10

FORCE OF NATURE. Torture-tested to dominate changeable conditions, this workhorse is mud-ready from winch to tail, including snorkeled intakes and Smart-Lok.

Engine

Rotax® 976 cc, V-twin, liquid cooled with strategically positioned engine air intake
Transmission

PRO-TORQ Transmission with Quick Response System (QRS), Electronic Drive Belt Protection, lower gearing ratio and high airflow ventilation with strategically positioned CVT air intake and exhaust
Wheels

14-in. (35.6 cm) cast-aluminum wheels
Suspension

Front: Arched double A-arm with sway bar / Rear: Arched TTA with external sway bar
Protection

Heavy-duty front steel bumper, HMWPE full skid plate, Aluminum rock sliders, Mudguards

Download spec sheet

Engine
Engine	HD10
Engine displacement	976
Type	HD10: 82 hp ( 61 kW), Rotax® 976 cc, V-twin, liquid cooled with strategically positioned engine air intake
Fuel Delivery System	Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission	PRO-TORQ CVT Transmission with Quick Response System (QRS), Electronic Drive Belt Protection, lower gearing ratio and high airflow ventilation with strategically positioned CVT air intake and exhaust Extra-L / H / N / R / P
Drive Train	Selectable Turf Mode / 2WD / 4WD TRAIL / 4WD MUD with exclusive SmartLok technology. Smart-Lok was developed in conjunction with TEAM Industries, a market leader in the drive train industry
Driving Assistance	Electronic Hill Descent Control / ECO / ECO Off / Work modes
Power Steering	Dynamic Power Steering (DPS)

Tires/Wheels
Front Tyres	ITP†* Cryptid† 30 x 9 x 14 in. (76.2 x 22.9 x 35.6 cm)
Rear Tyres	ITP* Cryptid 30 x 11 x 14 in. (76.2 x 27.9 x 35.6 cm)
Wheels	14 in. cast-aluminum

Breaks
Front	Dual 220 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Dual 220 mm ventilated disc brakes with hydraulic single-piston calipers

Dimensions
L x W x H	129.4 x 64 x 82 in. (328.6 x 162.6 x 208.3 cm)
Wheel Base	83 in. (211.5 cm)
Ground Clearance	15 in. (38.1 cm)
Chassis Cage	Profiled cage. ROPS approved
Dry Weight	1,697.6 lb (770 kg)
Cargo Box Dimensions	38 x 54.5 x 12 in. (96.5 x 138.4 x 30.5 cm)
Cargo Box Capacity	1,000 lb (454 kg)
Tailgate Load Capacity	250 lb (113.4 kg)
Storage Capacity	Total: 16.2 gal (61.3 L) Under dash: 6 gal (22.8 L) Waterproof and removable box under passenger seat: 5.6 gal (21 L) Dash: 2 gal (7.7 L) Water-resistant and removable toolbox: 1.7 gal (6.3 L) Armrests and cup holders: 0.9 gal (3.5 L)
Towing Capacity	2,500 lb (1134 kg)
Payload Capacity	1,500 lb (680 kg)
Fuel Capacity	10.6 gal (40 L)
Person Capacity	3

Suspensions
Front Suspension	Double A-arm / 10 in. (25.4 cm) travel
Front Shocks	Twin tube gas charged shocks
Rear Suspension	TTA with external sway bar / 10 in. (25.4 cm) travel
Rear Shocks	Twin tube gas charged shocks

Feature
Gauge	7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, ECO / ECO Off / Work modes, seat belt, diagnostics, clock, battery voltage, engine temperature
Battery	12 V (30 amp/h)
Magneto	650 W
Instrumentation	Two lighter type DC outlets, one in the console (20-A) and one in the under dash storage (20-A)
Lighting	140 W lighting output from four 35-W reflectors ensuring a wide visiblity and LED tail lights
Winch	Relocated 2,041 kg winch with synthetic rope and aluminum fairlead
Seat	VERSA-PRO bench seat with bolster seats for additional lateral support, passenger seats flipping up, adjustable driver seat, underside hooks, reinforced seat skin featuring X package trims and contoured bench to improve entrance /exit of the cab
Steering Wheel	Adjustable tilt steering
Protection	Heavy-duty front steel bumper, HMWPE full skid plate, aluminum rock sliders, mudguards
Hitch Type	2-in. hitch receiver

Warranty
Factory	2 years BRP limited warranty

2022 Traxter

Traxter DPS HD9

Traxter BASE HD9 T

Traxter XT HD10

Traxter PRO DPS HD10

Traxter MAX DPS HD9

Traxter XU HD9 T

Traxter PRO DPS HD10 T

Traxter XU HD7 T

Traxter BASE HD7 T

Traxter MAX DPS HD10 T

Traxter XU HD10 T

Traxter X mr HD10

2024 Traxter
