- Work
- 450 T: 38 hp / 570 T: 48 hp
- 26-in. Carlisle† ACT HD 6-ply tires
- Tri-Mode Dynamic Power Steering (DPS)
- Reinforced seat skin
- Increased ground clearance (29.2 cm)
-
Engine
450 : 38 hp, Rotax 427 cc single cylinder, liquid cooled 570: 48 hp, Rotax V-twin, liquid cooled
-
Suspension
Front: Double A-arm 22.9 cm travel/ Rear: Torsional Trailing arm Independent (TTI) 22.4 cm travel
-
Features
590 kg of towing capacity
-
Differential
Selectable 2WD / 4WD with Visco-Lok† auto-locking front differential
Engine Engine - 450
570
Engine displacement - 450
570
Type - 450: 38 hp, Rotax 427 cc single cylinder, liquid cooled
570: 48 hp, Rotax V-twin, liquid cooled
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI)
Transmission - CVT, P / R / N / H / L, standard engine braking
CVT, P / R / N / H / Extra Low L, standard engine braking
Drive Train - Selectable 2WD / 4WD with Visco-Lok‡ QE auto-locking front differential
Power Steering - Tri-Mode Dynamic Power Steering (DPS)
Tires/Wheels Front Tires - Carlisle† ACT HD 26 x 8 x 12-in. (66 x 20.3 x 30.5 cm)
Rear Tires - Carlisle† ACT HD 26 x 10 x 12-in. (66 x 25.4 x 30.5 cm)
Wheels - 12-in. steel
Breaks Front - Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Single 214 mm ventilated disc brake with hydraulic twin-piston caliper
Dimensions L x W x H - 211 x 117 x 124 cm
212 x 117 x 124 cm
Wheel Base - 129.5 cm
Ground Clearance - 29.2 cm
Dry Weight - 308 kg
319 kg
Rack Capacity - Front: 54.4 kg Rear: 109 kg
Storage Capacity - Rear: 10.9 L
Towing Capacity - 590 kg
Fuel Capacity - 20.5 L
Seat Height - 85.8 cm
Suspensions Front Suspension - Double A-arm 22.9 cm travel
Front Shocks - Oil
Rear Suspension - Torsional Trailing arm Independent (TTI) 22.4 cm travel
Rear Shocks - Oil
Feature Gauge - Multifunction Digital: Speedometer, tachometer, odometer, trip & hour meters, fuel, gear position, 4 x 4 indicator, diagnostics, clock
Instrumentation - Lighter type DC outlet in console, standard connector in the back (15-A)
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™)
Lighting - 70-W from dual 35-W front light / brake light
Winch - Prewired for available winch
Seat - Reinforced seat skin
Protection - N/A
Warranty Factory - 2 years BRP limited warranty
