2022Maverick X3 DS Turbo
-
Performance
- Desert / Trail
- 120 hp
- 64 in. width
- 20 in. (50.8 cm) of suspension travel
- 30 in. Maxxis Carnivore† tires, 14 in. cast-aluminum wheels
- Smart-Lok featuring 4WD TRAIL ACTIV mode
![/content/dam/global/en/can-am-off-road/my22/photos/vehicle-lineup/ssv/maverick-x3/maverick-x3-ds-turbo/ORV-SSV-MY22-MaverickX3-DS-Turbo-Octane-Blue-SKU0009DNG00-Studio-34FR-INTL.png]()
![octane-blue]()
THE BEST IS BETTER THAN EVER. High-performance at an MSRP that keeps our competitors up at night: the 2 or 4-seat 120 horsepower Maverick X3 DS Turbo thrills with next-generation go-anywhere.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD with front diff. lock
-
Shocks
FOX† 2.5 PODIUM Piggyback with QS3†
-
Suspension
Front: Double A-arm with sway bar / Rear: 4-link TTX with sway bar
-
Protection
Integrated front bumper, Quarter-doors, HMWPE full skid plate
-
Features
Rear tow hook, 650w magneto
Engine Engine - TURBO
Engine displacement - 900
Type - 120 hp, Rotax ACE (Advanced Combustion Efficiency) 900 cc Turbocharged Triple-cylinder engine, liquid cooled and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - Quick Response System X (QRS-X) CVT with high airflow, L / H / N / R / P
Drive Train - Lockable front differential with exclusive Smart-Lok* technology. True 4-mode traction system: 2WD/4WD with front diff. lock/4WD TRAIL ACTIV/4WD TRAIL
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tires - Maxxis Carnivore 30 x 10 x 14 in.
Rear Tires - Maxxis Carnivore 30 x 10 x 14 in.
Wheels - 14 in. cast-aluminum
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 132 x 64 x 65.4 in. (335.3 x 162.5 x 166.1 cm)
Wheel Base - 102 in. (259.1 cm)
Ground Clearance - 14 in. (35.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,546 lb (701.3 kg)
Rack Capacity - 200 lb (91 kg) with LinQ™ quick-attach
Storage Capacity - Total: 2.5 gal (9.4 L) Glove box: 1.6 gal (6.2 L) Central console: 0.8 gal (2.8 L) Cup holders: 0.1 gal (0.4 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Double A-arm with sway bar / 20 in. (50.8 cm) travel
Front Shocks - FOX† 2.5 PODIUM Piggyback with QS3† compression adjustment
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar / 20-in (50.8 cm) travel
Rear Shocks - FOX† 2.5 PODIUM Piggyback with QS3†compression adjustment and bottom-out control
Feature Gauge - 4.5 in. (11.4 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trips and hour meters, fuel, gear position, SPORT / ECO™ mode, seat belt and 4 x 4 indicator, front and rear diff lock indicators, diagnostics, clock, battery voltage, engine temperature, DPS mode
Magneto - 650 W
Instrumentation - Lighter type DC outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights
Winch - N/A
Protection - Integrated front bumper, Quarter-doors, HMWPE full skid plate, Rear tow hook
Warranty Factory - 2 years/15,000 km warranty, whichever comes first
-
-
-
Performance
- Desert / Dunes
- 200 hp
- 72 in. width
- Up to 24 in. (61 cm) of suspension travel
- Smart-Shox Technology, Smart-Lok featuring 4WD TRAIL ACTIV mode, Trophy truck inspired double A-arms
- 32 in. Maxxis Carnivore† tires, 14 in. cast-aluminum beadlock wheels
![/content/dam/global/en/can-am-off-road/my22/photos/vehicle-lineup/ssv/maverick-x3/maverick-x3-xrssas-turbo-rr/ORV-SSV-MY22-MaverickX3-XRSSAS-TurboRR-Intense-Blue-Carbon-Black-Chalk-Grey-SKU0007TNR00-Studio-34FR-INTL.png]()
![desert-tan---carbon-black---can-am-red]()
BUILT FOR THE VICTORY LAP. Run at the front of any pack with 200 horsepower, and Smart-Shox semi-active suspension to defy any playground.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD with front diff. lock
-
Shocks
Front: FOX† 2.5 PODIUM Piggyback with bypass and Smart-Shox Technology / Rear: FOX† 3.0 PODIUM Remote reservoir with bypass and Smart-Shox Technology
-
Suspension
Front: Trophy truck inspired double A-arm with sway bar / Rear: 4-link TTX with sway bar
-
Protection
Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate
-
Features
7.6 in. digital display with keypad, 850w magneto, X-package graphics/seats/signature, Rear tow hook
Engine Engine - TURBO RR
Engine displacement - 900
Type - 200 hp, Rotax ACE (Advanced Combustion Efficiency) 900 cc turbocharged triple-cylinder engine, liquid-cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - PDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L/H/N/R/P
Drive Train - Lockable front differential with exclusive Smart-Lok technology. True 4-mode traction system: 2WD/4WD with front diff. lock/4WD TRAIL ACTIV/4WD TRAIL
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tires - Maxxis Carnivore 32 x 10 x 14 in.
Rear Tires - Maxxis Carnivore 32 x 10 x 14 in.
Wheels - 14 in. cast-aluminum
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 132 x 72.7 x 68.5 in. (335.3 x 184.7 x 174 cm)
Wheel Base - 102 in. (259.1 cm)
Ground Clearance - 16 in. (40.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,699 lb (770.7 kg)
Rack Capacity - 200 lb (91 kg) with LinQ™ quick-attach
Storage Capacity - Total: 2.5 gal (9.4 L) Glove box: 1.6 gal (6.2 L) Central console: 0.8 gal (2.8 L) Cup holders: 0.1 gal (0.4 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Double A-arm with sway bar / 22-in. (55.9 cm) travel / Trophy truck inspired arms
Front Shocks - FOX 2.5 PODIUM piggyback with bypass and Smart-Shox Technology featuring DDA valve (Dynamic Damping Adjustment)
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar / 24-in (61 cm) travel
Rear Shocks - FOX 3.0 PODIUM remote reservoir with bypass and Smart-Shox Technology featuring DDA valve (Dynamic Damping Adjustment)
Feature Gauge - 7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, SPORT / ECO™ modes, seat belt, diagnostics, clock
Magneto - 850 W
Instrumentation - Lighter type DC Outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights with unique Can-Am LED signature
Winch - N/A
Protection - Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate, Rear tow hook
Warranty Factory - 2 years/15,000 km warranty, whichever comes first
-
-
-
Rock
- Performance
- 200 hp
- 72 in. width
- Up to 24 in. (61 cm) of suspension travel
- Smart-Lok featuring 4WD ROCK mode, Trophy truck inspired arched double A-arms
- 32 in. Maxxis Liberty† tires, 15 in. cast-aluminum beadlock wheels
![/content/dam/global/en/can-am-off-road/my22/photos/vehicle-lineup/ssv/maverick-x3/maverick-x3-xrc-72-turbo-rr/ORV-SSV-MY22-MaverickX3-XRC72-TurboRR-Chalk-Grey-Magma-Red-SKU0009MNC00-Studio-34FR-INTL.png]()
![chalk-gray---magma-red]()
ROCK ON ROCKS. Test your mettle and finally conquer the last mile: This Maverick X3 X rc Turbo RR has a 72 in. stance and is the ultimate factory rock-crawling side-by-side vehicle for leaving rivals at the bottom of the heap.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD ROCK / 4WD TRAIL / 2WD / 4WD with front diff. lock
-
Shocks
Front: FOX† 2.5 PODIUM RC2† Piggyback / Rear: FOX† 3.0 PODIUM RC2† Piggyback
-
Suspension
Front: Trophy truck inspired arched double A-arm with sway bar / Rear: 4-link TTX with sway bar and arched lower links
-
Protection
Front bumper, Half-doors, Aluminum roof, Intrusion bar, 4-point harness with shoulder pads, UHMWPE rock sliders, HMWPE skidplates, Full heavy duty with differential / Under bumper / Front and rear suspension arm
-
Features
4,500-lb winch with synthetic rope, 7.6 in. digital display with keypad, 850w magneto, X-package graphics/seats/signature, Rear tow hook
Engine Engine - TURBO RR
Engine displacement - 900
Type - 200 hp, Rotax ACE (Advanced Combustion Efficiency) 900 cc turbocharged triple-cylinder engine, liquid-cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - PDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L/H/N/R/P
Drive Train - Lockable front differential with exclusive Smart-Lok technology. True 4-mode traction system: 2WD/4WD with front diff. lock/4WD ROCK/4WD TRAIL
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tires - Maxxis Liberty† 32 x 10 x 15 in.
Rear Tires - Maxxis Liberty† 32 x 10 x 15 in.
Wheels - 15 in. cast-aluminum beadlock
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 134.5 x 72.8 x 68.5 in. (341.6 x 184.9 x 174 cm)
Wheel Base - 102 in. (259.1 cm)
Ground Clearance - 16 in. (40.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,843 lb (836 kg)
Rack Capacity - 200 lb (91 kg) with LinQ™ quick-attach
Storage Capacity - Total: 2.5 gal (9.4 L) Glove box: 1.6 gal (6.2 L) Central console: 0.8 gal (2.8 L) Cup holders: 0.1 gal (0.4 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Trophy truck inspired double arched A-arm with sway bar / 22-in. (55.9 cm) travel
Front Shocks - FOX† 2.5 PODIUM RC2† Piggyback with bypass, dual speed compression and rebound adjustments
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar and arched lower links / 24-in. (61 cm) travel
Rear Shocks - FOX† 3.0 PODIUM RC2† remote reservoir with bypass, dual speed compression and rebound adjustments
Feature Gauge - 7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, SPORT / ECO™ modes, seat belt, diagnostics, clock
Magneto - 850 W
Instrumentation - Lighter type DC Outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights with unique Can-Am LED signature
Winch - 4,500-lb (2,041 kg) winch with synthetic rope
Protection - Front bumper Half doors Aluminum roof Intrusion bar 4-point harness with shoulder pads UHMWPE rock sliders HMWPE skidplates: Full heavy-duty with differential/Under bumper/ Front and rear suspension arm Rear tow hook Front bumper, Half-doors, Aluminum roof, Intrusion bar, 4-point harness with shoulder pads, UHMWPE rock sliders, HMWPE skidplates: Full heavy duty with Differential, Under bumper, Front and rear suspension arm, Rear tow hook
Warranty Factory - 2 years/15,000 km warranty, whichever comes first
-
-
-
Performance
- Desert / Dunes
- 200 hp
- 72 in. width
- 22 in. (55.9 cm) of suspension travel
- Smart-Shox Technology, Smart-Lok featuring 4WD TRAIL ACTIV mode, Trophy truck inspired double A-arms
- 32 in. Maxxis Carnivore† tires, 14 in. cast-aluminum beadlock wheels
![/content/dam/global/en/can-am-off-road/my22/photos/vehicle-lineup/ssv/maverick-x3/maverick-x3-max-xrssas-turbo-rr/ORV-SSV-MY22-MaverickX3-MAX-XRSSAS-TurboRR-Intense-Blue-Carbon-Black-Chalk-Grey-SKU0009NNN00-Studio-34FR-INTL.png]()
![intense-blue--carbon-black---chalk-gray]()
BUILT FOR THE VICTORY LAP. Run at the front of any pack with 3 of your friends, 200 horsepower, Smart-Lok™ differential featuring Trail Activ mode and Smart-Shox semi-active suspension.
-
Differential
Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD with front diff. lock
-
Shocks
Front: FOX† 2.5 PODIUM Piggyback with bypass and Smart-Shox Technology / Rear: FOX† 3.0 PODIUM Remote reservoir with bypass and Smart-Shox Technology
-
Suspension
Front: Trophy truck inspired double A-arm with sway bar / Rear: 4-link TTX with sway bar
-
Protection
Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE full skid plate
-
Features
7.6 in. digital display with keypad, 850w magneto, X-package graphics/seats/signature, Rear tow hook
Engine Engine - TURBO RR
Engine displacement - 900
Type - 200 hp, Rotax ACE (Advanced Combustion Efficiency) 900 cc turbocharged triple-cylinder engine, liquid-cooled with integrated intercooler and high-perfomance air filter
Fuel Delivery System - Intelligent Throttle Control (iTC™) with Electronic Fuel Injection (EFI)
Transmission - PDrive primary and Quick Response System X (QRS-X) CVT with high airflow, L/H/N/R/P
Drive Train - Lockable front differential with exclusive Smart-Lok technology. True 4-mode traction system: 2WD/4WD with front diff. lock/4WD TRAIL ACTIV/4WD TRAIL
Power Steering - High torque Tri-Mode Dynamic Power Steering (DPS™)
Tires/Wheels Front Tires - Maxxis Carnivore 32 x 10 x 14 in.
Rear Tires - Maxxis Carnivore 32 x 10 x 14 in.
Wheels - 14 in. cast-aluminum beadlock
Breaks Front - Dual 262 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Dual 248 mm ventilated disc brakes with hydraulic twin-piston calipers
Dimensions L x W x H - 165 x 72.7 x 68.5 in. (419.1 x 184.7 x 174 cm)
Wheel Base - 135 in. (342.9 cm)
Ground Clearance - 16 in. (40.6 cm)
Chassis Cage - Dual-phase 980 steel
Dry Weight - 1,924 lb (872.7 kg)
Rack Capacity - 150 lb (68 kg) with LinQ™ quick-attach
Storage Capacity - Total: 3 gal (11.4 L) Glove box: 1.6 gal (6.2 L) Central console: 1.1 gal (4.1 L) Cup holders: 0.3 gal (1.1 L)
Fuel Capacity - 10.5 gal (40 L)
Suspensions Front Suspension - Double A-arm with sway bar / 22-in. (55.9 cm) travel / Trophy truck inspired arms
Front Shocks - FOX† 2.5 PODIUM RC2† Piggyback with bypass, dual speed compression and rebound adjustments
Rear Suspension - 4-link Torsional Trailing-arm X (TTX) with sway bar / 22-in. (55.9 cm) travel
Rear Shocks - FOX† 3.0 PODIUM RC2† remote reservoir with bypass, dual speed compression and rebound adjustments
Feature Gauge - 7.6 in. (19.3 cm) wide digital display with keypad: Speedometer, tachometer, odometer, trip and hour meters, fuel, gear position, SPORT / ECO™ modes, seat belt, diagnostics, clock
Magneto - 850 W
Instrumentation - Lighter type DC Outlet in central console
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™) with Start/ Stop button
Lighting - LED headlights and tail lights with unique Can-Am LED signature
Winch - N/A
Protection - Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate, Rear tow hook
Warranty Factory - 2 years/15,000 km warranty, whichever comes first
-
