Explore Renegade Packages & Specifications
-
2021
Renegade
Transportation and preparation not included.-
Performance
- Trail
- 570: 48 hp / 850: 78 hp
- 850: FOX† 1.5 PODIUM shocks
- 25 in. ITP Holeshot† ATR tires
- Front bumper
- 10.5 in. (26.7 cm) ground clearance
Command your adventures with power to spare and handling that hangs on to the ground better than ever. Navigating terrain wherever you roam hasn't been this much fun in ages—class-leading horsepower, agile responses, and astounding 4WD will do that.
-
Engine
570: Rotax 570 cc V-twin, liquid cooled 850: Rotax 854 cc V-twin, liquid cooled
-
Suspension
Front: Double arched A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
-
Wheels
12 in. cast-aluminum wheels
-
Protection
Front bumper
-
Differential
Selectable 2WD / 4WD with Visco-Lok† auto-locking front differential
Engine Engine - 570
850
Type - 570: 48HP, Rotax 570 cc V-twin, liquid cooled
850: 78HP, Rotax 854 cc V-twin, liquid cooled
Fuel Delivery System - 570: Electronic Fuel Injection (EFI)
850: Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI)
Transmission - CVT, P / R / N / H / L, standard engine braking
Drive Train - Selectable 2WD / 4WD with Visco-Lok auto-locking front differential
Power Steering - N/A
Tires/Wheels Front Tires - ITP Holeshot† ATR 25 x 8 x 12 in. (63.5 x 20.3 x 30.5 cm)
Rear Tires - ITP Holeshot† ATR 25 x 10 x 12 in. (63.5 x 25.4 x 30.5 cm)
Wheels - 12 in. cast-aluminum
Breaks Front - Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Single 214 mm ventilated disc brake with hydraulic twin-piston caliper
Dimensions L x W x H - 86 x 48 x 49 in. (218.4 x 121.9 x 124 cm)
Wheel Base - 51 in. (129.5 cm)
Ground Clearance - 10.5 in. (26.7 cm)
Dry Weight - 570: 628 lb (286 kg)
850: 681 lb (310 kg)
Rack Capacity - Rear: 35 lb (16 kg)
Storage Capacity - N/A
Towing Capacity - 1,300 lb (590 kg)
Fuel Capacity - 5.4 gal (20.5 L)
Seat Height - 34.5 in. (87.7 cm)
Suspensions Front Suspension - Arched double A-arm with front sway bar 9.2 in. (23.3cm) travel
Front Shocks - Oil
FOX† 1.5 Podium†
Rear Suspension - Torsional Trailing arm Independent (TTI) 9.9 in. (25,1 cm) travel
Rear Shocks - Oil
FOX† 1.5 PODIUM†
Feature Gauge - 4.5 in. digital display : Speedometer, tachometer, odometer, trip & hour meters,gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge & clock
Instrumentation - Lighter type DC outlet in console, standard connector in the back (15-A)
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™)
Lighting - 240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch - Prewired for available winch
Seat - Standard
Protection - Front bumper
Warranty Factory - 6-months BRP limited warranty
Extended Service Terms - B.E.S.T. terms available for up to 30 months
-
-
2021
Renegade X xc
Transportation and preparation not included.-
Performance
- Trail
- 850: 78 hp / 1000R: 91 hp
- FOX† 1.5 PODIUM RC2† shocks
- 25 in. ITP Holeshot† ATR tires
- Front bumper
- 10.5 in. (26.7 cm) ground clearance
Trail adventures with power to spare and handling that hangs on to terrain at your command—of course it's the X xc. Ripping the now 91 horsepower 1000R has never come with so much confidence over terrain—a fully re-engineered suspension will do that.
-
Engine
850: Rotax 854 cc V-twin, liquid cooled 1000R: Rotax 976 cc V-twin, liquid cooled
-
Suspension
Front: Double arched A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
-
Wheels
12 in. cast-aluminum beadlock wheels
-
Protection
Front bumper, Front & central skid plate, Aluminum taper-profile handlebar with full wrap handguards
-
Differential
Selectable 2WD / 4WD with Visco-Lok† QE auto-locking front differential
Engine Engine - 1000R
850
Type - 1000R: 91HP, Rotax 976 cc V-twin, liquid cooled
850: 78HP, Rotax 854 cc V-twin, liquid cooled
Fuel Delivery System - Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI)
Transmission - CVT, P / R / N / H / L, standard engine braking
Drive Train - Selectable 2WD / 4WD with Visco-Lok QE auto-locking front differential
Power Steering - Tri-Mode Dynamic Power Steering (DPS)
Tires/Wheels Front Tires - ITP Holeshot† ATR 25 x 8 x 12 in. (63.5 x 20.3 x 30.5 cm)
Rear Tires - ITP Holeshot† ATR 25 x 10 x 12 in. (63.5 x 25.4 x 30.5 cm)
Wheels - 12 in. cast-aluminum beadlock
Breaks Front - Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Single 214 mm ventilated disc brake with hydraulic twin-piston caliper
Dimensions L x W x H - 86 x 48 x 49 in. (218.4 x 121.9 x 124 cm)
Wheel Base - 51 in. (129.5 cm)
Ground Clearance - 10.5 in. (26.7 cm)
Dry Weight - 1000R: 710 lb (323 kg)
850: 686 lb (312 kg)
Rack Capacity - Rear: 35 lb (16 kg)
Storage Capacity - N/A
Towing Capacity - 1,300 lb (590 kg)
Fuel Capacity - 5.4 gal (20.5 L)
Seat Height - 34.5 in. (87.7 cm)
Suspensions Front Suspension - Arched double A-arm with front sway bar 9.2 in. (23.3cm) travel
Front Shocks - FOX† 1.5 PODIUM† RC2
Rear Suspension - Torsional Trailing arm Independent (TTI) 9.9 in. (25,1 cm) travel
Rear Shocks - FOX† 1.5 PODIUM† RC2
Feature Gauge - 4.5 in. digital display : Speedometer, tachometer, odometer, trip & hour meters,gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge & clock
Instrumentation - Lighter type DC outlet in console, standard connector in the back (15-A)
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™)
Lighting - 240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch - Prewired for available winch
Seat - Standard
Protection - Front bumper, Aluminum taper-profile handlebar with full wrap handguards and Front & central skid plate
Warranty Factory - 6-months BRP limited warranty
Extended Service Terms - B.E.S.T. terms available for up to 30 months
-
-
2021
Renegade X mr 570
Transportation and preparation not included.-
Mud
- Trail
- Performance
- 570: 48 hp
- FOX† 1.5 PODIUM shocks
- 28 in. ITP Mega Mayhem† tires
- Front & rear bumpers
- 12 in. (30.5 cm) ground clearance
THE MUD HAS MET ITS MATCH. Mud tires, snorkeled Rotax V-Twin engine, underbody protection & FOX 1.5 PODIUM shocks—ensure the deep end is more inviting than ever.
-
Engine
Rotax 570 cc V-twin, snorkeled, liquid cooled
-
Suspension
Front: Double arched A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
-
Wheels
12 in. cast-aluminum beadlock wheels
-
Protection
Front & rear bumpers, Front & central aluminum skid plate, Aluminum taper-profile handlebar with grab handle and full wrap handguards, Mudguards
-
Differential
Selectable 2WD / 4WD with Visco-Lok† QE auto-locking front differential
Engine Engine - 570
Type - 48HP, Rotax 570 cc V-twin, snorkeled, liquid cooled
Fuel Delivery System - Electronic Fuel Injection (EFI)
Transmission - CVT, P / R / N / H / L, standard engine braking
Drive Train - Selectable 2WD / 4WD with Visco-Lok QE auto-locking front differential
Power Steering - Tri-Mode Dynamic Power Steering (DPS)
Tires/Wheels Front Tires - ITP Mega Mayhem 28 x 8 x 12 in. (71.1 x 20.3 x 30.5 cm)
Rear Tires - ITP Mega Mayhem 28 x 10 x 12 in. (71.1 x 25.4 x 30.5 cm)
Wheels - 12 in. cast-aluminum beadlock
Breaks Front - Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Single 214 mm ventilated disc brake with hydraulic twin-piston caliper
Dimensions L x W x H - 83 x 50 x 56 in. (224 x 127 x 131 cm)
Wheel Base - 51 in. (129.5 cm)
Ground Clearance - 12 in. (30.5 cm)
Dry Weight - 865 lb (393 kg)
Rack Capacity - Rear: 35 lb (16 kg)
Storage Capacity - N/A
Towing Capacity - 1,300 lb (590 kg)
Fuel Capacity - 5.4 gal (20.5 L)
Seat Height - 35.25 in. (89.5 cm)
Suspensions Front Suspension - Arched double A-arm with front sway bar
Front Shocks - FOX† 1.5 PODIUM†
Rear Suspension - Torsional Trailing arm Independent (TTI)
Rear Shocks - FOX† 1.5 PODIUM†
Feature Gauge - 4.5 in. digital display : Speedometer, tachometer, odometer, trip & hour meters,gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge & clock
Instrumentation - Lighter type DC outlet in console, standard connector in the back (15-A)
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™)
Lighting - 240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch - Prewired for available winch
Seat - Standard
Protection - Front & rear bumpers, Aluminum taper-profile handlebar with grab handle full wrap handguards, Mudguards, front & central aluminum skid plate
Warranty Factory - 6-months BRP limited warranty
Extended Service Terms - B.E.S.T. terms available for up to 30 months
-
-
2021
Renegade X mr 1000R
Transportation and preparation not included.-
Mud
- Trail
- 1000R: 91 hp
- FOX† 1.5 PODIUM QS3† shocks
- 30 in. ITP Cryptid† tires
- Available Visco-4Lok, 3,500-lb winch, Front & rear bumpers
- 12.5 in. (31.8 cm) ground clearance
Our most powerful ATV! The new 91-hp Renegade X mr 1000R is built strong to ride fast & far through mud. With next-generation suspension and Visco-4Lok front differential, the game has truly changed.
-
Engine
Rotax 976 cc V-twin, liquid cooled
-
Suspension
Front: Double arched A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
-
Wheels
14 in. cast-aluminum beadlock wheels
-
Protection
Front & rear bumpers, Front & central aluminum skid plate, Aluminum taper-profile handlebar with grab handle and full wrap handguards, Mudguards
-
Differential
Manta Green: Selectable 2WD / 4WD with Visco-Lok† QE auto-locking front differential Neo Yellow: Selectable 2WD / 4WD / Lock 4WD with Visco-4Lok† front differential
Engine Engine - 1000R
Type - 91HP, Rotax 976 cc V-twin, snorkeled, liquid cooled
Fuel Delivery System - Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI)
Transmission - CVT, P / R / N / H / Extra Low L, standard engine braking
Drive Train - Neo Yellow: Selectable 2WD / 4WD / Lock 4WD with Visco-4Lok front differential
Selectable 2WD / 4WD with Visco-Lok QE auto-locking front differential
Power Steering - Tri-Mode Dynamic Power Steering (DPS)
Tires/Wheels Front Tires - ITP Cryptid 30 x 9 x 14 in. (76.6 x 22.9 x 35.6 cm)
Rear Tires - ITP Cryptid 30 x 9 x 14 in. (76.6 x 22.9 x 35.6 cm)
Wheels - 14 in. cast-aluminum beadlock
Breaks Front - Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear - Single 214 mm ventilated disc brake with hydraulic twin-piston calipers
Dimensions L x W x H - 83 x 50 x 56 in. (224 x 127 x 131 cm)
Wheel Base - 51 in. (129.5 cm)
Ground Clearance - 12 .5 in. (31.8 cm)
Dry Weight - 991 lb (450 kg)
Rack Capacity - Rear: 35 lb (16 kg)
Storage Capacity - N/A
Towing Capacity - 1,300 lb (590 kg)
Fuel Capacity - 5.4 gal (20.5 L)
Seat Height - 36.75 in. (93.3 cm)
Suspensions Front Suspension - Arched double A-arm with front sway bar
Front Shocks - FOX† 1.5 PODIUM† QS3
Rear Suspension - Torsional Trailing arm Independent (TTI)
Rear Shocks - FOX† 1.5 PODIUM† QS3
Feature Gauge - 4.5 in. digital display : Speedometer, tachometer, odometer, trip & hour meters,gear position, 4 x 4 indicator, temperature, engine lights, electronic fuel gauge & clock
Instrumentation - Lighter type DC outlet in console, standard connector in the back (15-A)
Anti Theft System - RF Digitally Encoded Security System (D.E.S.S.™)
Lighting - 240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch - 3,500-lb (1,588 kg) winch
Seat - Standard
Protection - Neo Yellow: Front & rear bumpers, Aluminum taper-profile handlebar with grab handle full wrap handguards, Mudguards, front & central aluminum skid plate
Warranty Factory - 6-months BRP limited warranty
Extended Service Terms - B.E.S.T. terms available for up to 30 months
-
