2020

Renegade

Performance
Trail

570: 48 hp / 850: 78 hp
850: FOX† 1.5 PODIUM shocks
25-in. ITP Holeshot† ATR tires
10.5 in. (26.7 cm) ground clearance

Renegade

Command your adventures with power to spare and handling that hangs on to the ground better than ever. Navigating terrain wherever you roam hasn't been this much fun in ages—class-leading horsepower, agile responses, and astounding 4WD will do that.

Engine

570: Rotax 570 cc V-twin, liquid cooled 850: Rotax 854 cc V-twin, liquid cooled
Suspension

Front: Arched double A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
Wheels

12-in. cast-aluminum wheels
Protection

Front bumper
Differential

Selectable 2WD / 4WD with Visco-Lok† auto-locking front differential

Download spec sheet

Engine
Engine	570 850
Engine displacement	570 850
Type	570: 48HP, Rotax 570 cc V-twin, liquid cooled 850: 78HP, Rotax 854 cc V-twin, liquid cooled
Fuel Delivery System	570: Electronic Fuel Injection (EFI) 850: Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI)
Transmission	CVT, P / R / N / H / L, standard engine braking
Drive Train	Selectable 2WD / 4WD with Visco-Lok auto-locking front differential
Power Steering	N/A

Tires/Wheels
Front Tires	ITP Holeshot† ATR 25 x 8 x 12 in. (63.5 x 20.3 x 30.5 cm)
Rear Tires	ITP Holeshot† ATR 25 x 10 x 12 in. (63.5 x 25.4 x 30.5 cm)
Wheels	12-in. cast-aluminum

Breaks
Front	Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Single 214 mm ventilated disc brake with hydraulic twin-piston caliper

Dimensions
L x W x H	86 x 48 x 49 in. (218.4 x 121.9 x 124 cm)
Wheel Base	51 in. (129.5 cm)
Ground Clearance	10.5 in. (26.7 cm)
Estimated Dry Weight*	570: 628 lb (286 kg) 850: 681 lb (310 kg)
Rack Capacity	Rear: 35 lb (16 kg)
Storage Capacity	N/A
Towing Capacity	1,300 lb (590 kg)
Fuel Capacity	5.4 gal (20.5 L)
Seat Height	34.5 in. (87.7 cm)

Suspensions
Front Suspension	Arched double A-arm with front sway bar 9.2 in. (23.3cm) travel
Front Shocks	Oil FOX† 1.5 Podium†
Rear Suspension	Torsional Trailing arm Independent (TTI) 9.9 in. (25,1 cm) travel
Rear Shocks	Oil FOX† 1.5 PODIUM†

Feature
Gauge	Multifunction digital: Speedometer, tachometer, odometer, trip & hour meters, fuel, gear position, 4 x 4 indicator, diagnostics, clock
Instrumentation	Lighter type DC Outlet in console, standard connector in the back (15-A)
Anti Theft System	RF Digitally Encoded Security System (D.E.S.S.™)
Lighting	240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch	Prewired for available winch
Seat	Standard
Protection	Front bumper

Warranty
Factory	6-months BRP limited warranty
Extended Service Terms	B.E.S.T. terms available for up to 30 months

2020

Renegade X xc

Performance
Trail

850: 78 hp / 1000R: 91 hp
FOX† 1.5 PODIUM RC2† shocks
25-in. ITP Holeshot† ATR tires
Tri-Mode Dynamic Power Steering (DPS)
10.5 in. (26.7 cm) ground clearance

Renegade X xc

Trail adventures with power to spare and handling that hangs on to terrain at your command—of course it's the X xc. Ripping the now 91 horsepower 1000R has never come with so much confidence over terrain—a fully re-engineered suspension will do that.

/content/dam/global/en/can-am-off-road/my20/vehicle-line-up/atv/renegade/renegade-x-xc/Renegade-X-xc-1000R-Black-Can-Am-Red_3-4-front.png

Engine

850: Rotax 854 cc V-twin, liquid cooled 1000R: Rotax 976 cc V-twin, liquid cooled
Suspension

Front: Arched double A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
Wheels

12-in. cast-aluminum beadlock wheels
Protection

Front bumper, Aluminum taper-profile handlebar with wind deflectors and square pad, Front & central skid plate
Differential

Selectable 2WD / 4WD with Visco-Lok† QE auto-locking front differential

Download spec sheet

Engine
Engine	850 1000R
Engine displacement	850 1000
Type	850: 78HP, Rotax 854 cc V-twin, liquid cooled 1000R: 91HP, Rotax 976 cc V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI)
Transmission	CVT, P / R / N / H / L, standard engine braking
Drive Train	Selectable 2WD / 4WD with Visco-Lok QE auto-locking front differential
Power Steering	Tri-Mode Dynamic Power Steering (DPS)

Tires/Wheels
Front Tires	ITP Holeshot† ATR 25 x 8 x 12 in. (63.5 x 20.3 x 30.5 cm)
Rear Tires	ITP Holeshot† ATR 25 x 10 x 12 in. (63.5 x 25.4 x 30.5 cm)
Wheels	12-in. cast-aluminum beadlock

Breaks
Front	Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Single 214 mm ventilated disc brake with hydraulic twin-piston caliper

Dimensions
L x W x H	86 x 48 x 49 in. (218.4 x 121.9 x 124 cm)
Wheel Base	51 in. (129.5 cm)
Ground Clearance	10.5 in. (26.7 cm)
Estimated Dry Weight*	850: 686 lb (312 kg) 1000R: 710 lb (323 kg)
Rack Capacity	Rear: 35 lb (16 kg)
Storage Capacity	N/A
Towing Capacity	1,300 lb (590 kg)
Fuel Capacity	5.4 gal (20.5 L)
Seat Height	34.5 in. (87.7 cm)

Suspensions
Front Suspension	Arched double A-arm with front sway bar 9.2 in. (23.3cm) travel
Front Shocks	FOX† 1.5 PODIUM† RC2
Rear Suspension	Torsional Trailing arm Independent (TTI) 9.9 in. (25,1 cm) travel
Rear Shocks	FOX† 1.5 PODIUM† RC2

Feature
Gauge	Multifunction digital: Speedometer, tachometer, odometer, trip & hour meters, fuel, gear position, 4 x 4 indicator, diagnostics, clock
Instrumentation	Lighter type DC Outlet in console, standard connector in the back (15-A)
Anti Theft System	RF Digitally Encoded Security System (D.E.S.S.™)
Lighting	240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch	Prewired for available winch
Seat	Standard
Protection	Front bumper, Aluminum taper-profile handlebar with full wrap handguards and Front & central skid plate

Warranty
Factory	6-months BRP limited warranty
Extended Service Terms	B.E.S.T. terms available for up to 30 months

2020

Renegade X mr 570

Mud
Performance
Trail

570: 48 hp
FOX† 1.5 PODIUM shocks
28-in. ITP Mega Mayhem† tires
Tri-Mode Dynamic Power Steering (DPS)
11 in. (30.5 cm) ground clearance

Renegade X mr 570

THE MUD HAS MET ITS MATCH. Mud tires, snorkeled Rotax V-Twin engine, underbody protection & Fox 1.5 PODIUM shocks—ensure the deep end is more inviting than ever.

Engine

Rotax 570 cc V-twin, snorkeled, liquid cooled
Suspension

Front: Arched double A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
Wheels

12-in. cast-aluminum beadlock wheels
Protection

Front & rear bumpers, Aluminum taper-profile handlebar with grab handle, wind deflectors and square pad, Mudguards, front & central aluminum skid plate
Differential

Selectable 2WD / 4WD with Visco-Lok† QE auto-locking front differential

Download spec sheet

Engine
Engine	570
Engine displacement	570
Type	48HP, Rotax 570 cc V-twin, snorkeled, liquid cooled
Fuel Delivery System	Electronic Fuel Injection (EFI)
Transmission	CVT, P / R / N / H / L, standard engine braking
Drive Train	Selectable 2WD / 4WD with Visco-Lok QE auto-locking front differential
Power Steering	Tri-Mode Dynamic Power Steering (DPS)

Tires/Wheels
Front Tires	ITP Mega Mayhem 28 x 8 x 12 in. (71.1 x 20.3 x 30.5 cm)
Rear Tires	ITP Mega Mayhem 28 x 10 x 12 in. (71.1 x 25.4 x 30.5 cm)
Wheels	12-in. cast-aluminum beadlock

Breaks
Front	Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Single 214 mm ventilated disc brake with hydraulic twin-piston caliper

Dimensions
L x W x H	83 x 50 x 56 in. (224 x 127 x 131 cm)
Wheel Base	51 in. (129.5 cm)
Ground Clearance	12 in. (30.5 cm)
Estimated Dry Weight*	865 lb (393 kg)
Rack Capacity	Rear: 35 lb (16 kg)
Storage Capacity	N/A
Towing Capacity	1,300 lb (590 kg)
Fuel Capacity	5.4 gal (20.5 L)
Seat Height	35.25 in. (89.5 cm)

Suspensions
Front Suspension	Arched double A-arm with front sway bar
Front Shocks	FOX† 1.5 PODIUM†
Rear Suspension	Torsional Trailing arm Independent (TTI)
Rear Shocks	FOX† 1.5 PODIUM†

Feature
Gauge	Multifunction digital: Speedometer, tachometer, odometer, trip & hour meters, fuel, gear position, 4 x 4 indicator, diagnostics, clock
Instrumentation	Lighter type DC Outlet in console, standard connector in the back (15-A)
Anti Theft System	RF Digitally Encoded Security System (D.E.S.S.™)
Lighting	240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch	Prewired for available winch
Seat	3,000-lb (1,361 kg) WARN† winch with roller fairlead
Protection	Front & rear bumpers, Aluminum taper-profile handlebar with grab handle full wrap handguards, Mudguards, front & central aluminum skid plate

Warranty
Factory	6-months BRP limited warranty
Extended Service Terms	B.E.S.T. terms available for up to 30 months

2020

Renegade X mr 1000R

Mud
Performance
Trail

1000R: 91 hp
FOX† 1.5 PODIUM QS3† shocks
30-in. ITP Cryptid† tires
Tri-Mode Dynamic Power Steering (DPS)
12.5 in. (31.8 cm) ground clearance

Renegade X mr 1000R

Most powerful ATV is the new 91-hp Renegade X mr 1000R built strong to ride fast & far through mud, with next-generation suspension to dominate off-road

/content/dam/global/en/can-am-off-road/my20/vehicle-line-up/atv/renegade/renegade-x-mr-1000r/Renegade-X-mr-1000R-Iron-Gray-Manta-Green_3-4-front.png

Most powerful ATV is the new 91-hp Renegade X mr 1000R built strong to ride fast & far through mud, with next-generation suspension to dominate off-road

Engine

Rotax 976 cc V-twin, liquid cooled
Suspension

Front: Arched double A-arm with front sway bar / Rear: Torsional Trailing arm Independent (TTI)
Wheels

14-in. cast-aluminum beadlock wheels
Protection

Front & rear bumpers, Aluminum taper-profile handlebar with grab handle, wind deflectors and square pad, Mudguards, front & central aluminum skid plate
Differential

Selectable 2WD / 4WD with Visco-Lok† QE auto-locking front differential

Download spec sheet

Engine
Engine	1000R
Engine displacement	1000
Type	91HP, Rotax 976 cc V-twin, liquid cooled
Fuel Delivery System	Intelligent Throttle Control (iTC™️) with Electronic Fuel Injection (EFI)
Transmission	CVT, P / R / N / H / Extra Low L, standard engine braking
Drive Train	Selectable 2WD / 4WD with Visco-Lok QE auto-locking front differential
Power Steering	Tri-Mode Dynamic Power Steering (DPS)

Tires/Wheels
Front Tires	ITP Cryptid 30 x 9 x 14 in. (76.6 x 22.9 x 35.6 cm)
Rear Tires	ITP Cryptid 30 x 9 x 14 in. (76.6 x 22.9 x 35.6 cm)
Wheels	14-in. cast-aluminum beadlock

Breaks
Front	Dual 214 mm ventilated disc brakes with hydraulic twin-piston calipers
Rear	Single 214 mm ventilated disc brake with hydraulic twin-piston caliper

Dimensions
L x W x H	84 x 50 x 56 in. (224 x 127 x 131 cm)
Wheel Base	51 in. (129.5 cm)
Ground Clearance	12 .5 in. (31.8 cm)
Estimated Dry Weight*	991 lb (450 kg)
Rack Capacity	Rear: 35 lb (16 kg)
Storage Capacity	N/A
Towing Capacity	1,300 lb (590 kg)
Fuel Capacity	5.4 gal (20.5 L)
Seat Height	36.75 in. (93.3 cm)

Suspensions
Front Suspension	Arched double A-arm with front sway bar
Front Shocks	FOX† 1.5 PODIUM† QS3
Rear Suspension	Torsional Trailing arm Independent (TTI)
Rear Shocks	FOX† 1.5 PODIUM† QS3

Feature
Gauge	Multifunction digital: Speedometer, tachometer, odometer, trip & hour meters, fuel, gear position, 4 x 4 indicator, diagnostics, clock
Instrumentation	Lighter type DC Outlet in console, standard connector in the back (15-A)
Anti Theft System	RF Digitally Encoded Security System (D.E.S.S.™)
Lighting	240 W from 4 fender mounted projector beam headlamps (60-W) with tail light / brake light
Winch	3,000-lb (1,361 kg) WARN† winch with roller fairlead
Seat	Standard
Protection	Front & rear bumpers, Aluminum taper-profile handlebar with grab handle, wind deflectors and square pad, Mudguards, front & central aluminum skid plate

Warranty
Factory	6-months BRP limited warranty
Extended Service Terms	B.E.S.T. terms available for up to 30 months
